производитель:

технические характеристики

• Body Material: Brass
• Body Style: Straight
• Brand: HUBER+SUHNER
• Contact Material: Brass
• Contact Type: Socket(Female)
• Factory Pack Quantity: Factory Pack Quantity: 750
• Gender: Jack(Socket)
• Impedance: 50 Ohms
• Isolation: Non-Isolated
• Manufacturer: HUBER+SUHNER
• Maximum Frequency: 6 GHz
• Maximum Operating Temperature: +155 C
• Minimum Operating Temperature: -55 C
• Mounting Style: SMD/SMT
• Orientation: Straight
• Packaging: Reel, Cut Tape
• Part # Aliases: 22658306
• Polarity: Standard
• Product Category: RF Connectors/Coaxial Connectors
• Product Type: RF Connectors/Coaxial Connectors
• Product: PCB Connectors
• RF Series: MCX
• Series: MCX
• Subcategory: RF Interconnects
• Termination Style: Solder
• Automotive: No
• Body Orientation: Straight
• Contact Gender: F
• Contact Plating: Gold Over Nickel
• ECCN (US): EAR99
• EU RoHS: Compliant with Exemption
• Gender: F
• Impedance (Ohm): 50
• Mating Cycle (Cycles): 500
• Mating System: Snap-On
• Maximum Operating Temperature (°C): 155
• Minimum Operating Temperature (°C): -55
• Mounting: Surface Mount
• Operating Frequency (Hz): 0 to 6G
• Packaging: Tape and Reel
• Part Status: Active
• Polarity: Standard
• PPAP: No
• Termination Method: Solder
• Type: MCX
• Alias/AKA: 22658306
• COO: CH
• RoHS: Yes
• Supplier Standard Pack: 750
• Единица измерения: шт
