технические характеристики

• Body Finish: Gold
• Body Material: Brass
• Body Style: Right Angle
• Brand: HUBER+SUHNER
• Cable Type: RG-178B/U, 196A/U
• Contact Material: Brass
• Contact Plating: Gold
• Contact Termination: Solder
• Contact Type: Pin(Male)
• Factory Pack Quantity: Factory Pack Quantity: 1
• Gender: Plug(Pin)
• Impedance: 50 Ohms
• Isolation: Non-Isolated
• Manufacturer: HUBER+SUHNER
• Maximum Frequency: 6 GHz
• Maximum Operating Temperature: +155 C
• Minimum Operating Temperature: -55 C
• Mounting Style: Cable Mount/Free Hanging
• Orientation: Right Angle
• Part # Aliases: 22645955
• Polarity: Standard
• Product Category: RF Connectors/Coaxial Connectors
• Product Type: RF Connectors/Coaxial Connectors
• Product: Connectors
• RF Series: MMCX
• Series: MMCX
• Subcategory: RF Interconnects
• Termination Style: Crimp
• Body Orientation: Right Angle
• Body Plating: Gold
• Cable Type: RG178 B/U, RG196 A/U
• Coaxial Connector Type: MMCX Connector
• Contact Material: Beryllium Copper
• Contact Plating: Gold
• Gender: Male
• Impedance: 50Ω
• Maximum Operating Temperature: +155°C
• Minimum Operating Temperature: -55°C
• Mounting Type: Cable Mount
• Operating Frequency: 0 to 6GHz
• Termination Method: Crimp
• Body Material: Brass
• Mounting Style: Cable
• Operating Temp Range: -55C to 155C
• Packaging: SINGLE
• Product Depth (mm): 3.5(mm)
• Product Height (mm): 9(mm)
• Product Length (mm): 7(mm)
• Rad Hardened: No
• Terminate To: Coaxial Cable
• Termination: Crimp
• Type: MMCX
• Вес, г: 10
