технические характеристики

• Body Material: Brass
• Coaxial Cable Types: RG-223/U
• Contact Material: Beryllium Copper
• Contact Plating: Gold over Nickel
• Frequency Max.: 11 GHz
• Gender: Socket
• Impedance: 50 Ohm
• Mounting Type: Cable Mount
• Orientation: Straight
• RF Connector Type: TNC
• Termination Type: Crimp Terminal
• Cable Group: RG-142, 223
• Center Contact Material: Beryllium Copper
• Connector Style: TNC
• Connector Type: Jack, Female Socket
• Contact Termination: Crimp
• Fastening Type: Threaded
• Frequency - Max: 11 GHz
• Housing Color: Silver
• Mounting Feature: Bulkhead-Front Side Nut
• Number of Ports: 1
• Shield Termination: Crimp
