технические характеристики

• Body Finish: Gold
• Body Material: Beryllium Copper, Copper Alloy
• Body Style: Straight
• Brand: HUBER+SUHNER
• Cable Type: EZ-47-TP-M17, SUCOFORM-47-CU
• Contact Material: Beryllium Copper, Copper Alloy
• Contact Plating: Gold
• Contact Termination: Solder
• Contact Type: Socket(Female)
• Factory Pack Quantity: Factory Pack Quantity: 1
• Gender: Jack(Socket)
• Impedance: 50 Ohms
• Isolation: Non-Isolated
• Manufacturer: HUBER+SUHNER
• Maximum Frequency: 18 GHz
• Maximum Operating Temperature: +125 C
• Minimum Operating Temperature: -65 C
• Mounting Style: Flange Mount
• Orientation: Straight
• Part # Aliases: 22642391
• Polarity: Standard
• Product Category: RF Connectors/Coaxial Connectors
• Product Type: RF Connectors/Coaxial Connectors
• Product: Connectors
• RF Series: SMA
• Series: SMA
• Subcategory: RF Interconnects
• Termination Style: Solder
• Body Orientation: Straight
• Bulkhead: No
• Cable Type: Coaxial
• Coaxial Connector Type: SMA Connector
• Gender: Female
• Impedance: 50Ω
• Mounting Type: Flange Mount
• Polarity: Normal
• Series: 25_SMA-50-1-4/111_NE
• Termination Method: Solder
• Cable Group: 0.047" Semi Rigid
• Center Contact Material: Beryllium Copper
• Connector Style: SMA
• Connector Type: Jack, Female Socket
• Contact Termination: Solder
• Fastening Type: Threaded
• Frequency - Max: 18 GHz
• Housing Color: Gold
• Mounting Feature: Flange
• Number of Ports: 1
• Shield Termination: Solder
• Вес, г: 1.9
